Ethernet OAM (Operations, Administration, and Maintenance)
Left running head:
Chapter name (automatic)
404
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
OAM CONFIGURATION COMMANDS
TO ENTER OAM CONFIGURATION MODE
E
XAMPLE
ALU(config)# oam
ALU(config-oam)#
T
O CONFIGURE MAINTENANCE DOMAIN (MD)
E
XAMPLE
ALU(config-oam)# eth-cfm domain 1 name string domain123 level 1
ALU(config-oam)# no eth-cfm domain 1
Command (in CM) Description
oam This command enters the OAM
configuration mode.
Command (in OAM CM) Description
eth-cfm domain <0-65535> [name
{dns <dns-name>|mac <mac-
address>|string <string>}
level <0-7>]
This command is used to configure a
MD. This command also allows you to
configure an identity for the MD (index
and name) and the domain level.
Domain level is used to differentiate
various administrative networks like
customer network, service provider
network and operator network. Domain
levels are assigned based on the
administrative network.
Note: It is preferable to set the
domain level as 6 or 7 for a
MD.
no eth-cfm domain <0-65535>
[name {dns <dns-name>|mac
<mac-address>|string <string>}
<md-name> level <0-7>]
This command is used to delete a MD.
Note: You cannot delete a MD if its
associated with a MA. First
delete the MA to delete the
MD.
