POLICY MAP CONFIGURATION
Notes:
1. A policy map can have a maximum of 16 traffic classes including the default class.
By default, the default-class exists for a policy map.
2. A Traffic Class is defined by using the ‘class’ command. ‘Class’ command takes
an already defined class map or the keyword ‘class-default’ (to configure the
default class) as an argument.
TO CONFIGURE A POLICY MAP
EXAMPLE
ALU(config)# policy-map P1
ALU(config-qos-P1)#
ALU(config-qos-P1)# no policy-map P1
Policy-map P1 deleted.
T
O CONFIGURE A POLICY MAP DESCRIPTION
E
XAMPLE
ALU(config-qos-P1)# description P1 is the name of the policy-
map
ALU(config-qos-P1)# show policy-map P1
policy-map P1
description P1 is the name of the Policy Map
Command (in CM) Description
policy-map <policy-map name> This command is used to configure a policy
map.
no policy-map <policy-map
name>
This removes a user configured policy-map.
Note: You cannot remove a policy
map if it has been attached to
an interface either in ingress or
egress direction.
Command (in Policy-map Mode) Description
description <line> The description for the policy map
configured.
