OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
PORT MONITORING CONFIGURATION
The following lists the steps to configure Port Monitoring on the OmniAccess 5740
USG:
PORT MONITORING CONFIGURATION STEPS
Step 1: Configure L2 interface.
ALU(config)# interface switchport <slot/port>
ALU(config-if switchport<slot/port>)#
Example:
ALU(config)# interface switchport 1/0
ALU(config-if switchport1/0)#
Note: The L2 interface on which port monitoring is being configured should not be in ‘Trunk/
Hybrid’ mode. And, also 802.1X should not be configured on the interface.
Step 2: Administratively bring up the interface.
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if switchport1/0)# no shutdown
Step 3: Configure Port Monitoring. See “To Configure Port Monitoring”
Step 4: View port monitoring configuration details. “To View Port Monitor Details”
