PBR CONFIGURATION
This section includes the following:
• “PBR Configuration Steps”
• “PBR Configuration Flow”
• “PBR Configuration Commands”
PBR CONFIGURATION STEPS
This section lists the steps for configuring policy based routing on OmniAccess
5740 USG.
Step 1: Configure the match-lists using the common classifiers syntax. (Refer to
the chapter on “Common Classifiers” in this guide).
Step 2: Configure an IP policy. See “To Configure an IP Policy”
• Configure a Rule inside an IP policy. See “To Configure a Rule for an IP
Policy”
Attach an IP Policy to an Interface
Step 3: Enter into Interface Configuration Mode
ALU(config)# interface <name>
Example:
ALU(config)# interface GigabitEthernet3/0
ALU(config-if GigabitEthernet3/0)#
Note: IP policy can be configured on any interface.
Step 4: Administratively bring up the interface
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if GigabitEthernet3/0)# no shutdown
Step 5: Configure IP address for the interface
ALU(config-if <interface-name>)# ip address {<ip-
address subnet-mask>|<ip-address/prefix-length>}
Example:
ALU(config-if GigabitEthernet3/0)# ip address
20.20.20.20/24
