Multicast Routing
Left running head:
Chapter name (automatic)
614
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
PIM CONFIGURATION
This section includes the following:
“PIM Configuration Steps”
“PIM Configuration Flow”
“PIM Configuration Commands”
“Show Commands in PIM”
PIM CONFIGURATION STEPS
The steps given below helps in configuring PIM routing on the OmniAccess 5740
USG.
Step 1: Configure an interface. Enter Interface Configuration Mode.
ALU(config)# interface <name>
Example:
ALU(config)# interface GigabitEthernet3/0
ALU(config-if GigabitEthernet3/0)#
Note: PIM can be configured on Layer 3 interfaces.
Step 2: Administratively bring up the interface
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if GigabitEthernet3/0)# no shutdown
Step 3: Configure IP address for the interface
ALU(config-if <interface-name>)# ip address {<ip-
address subnet-mask>|<ip-address/prefix-length>}
Example:
ALU(config-if GigabitEthernet3/0)# ip address
20.20.20.20/24
Step 4: Enable Multicast routing. See “To Enable Multicast Routing”
Step 5: Enable PIM on an interface:. See “To Enable PIM on an Interface”
Step 6: Configure PIM Static RP. See “To Configure PIM Static RP”
Or
Configure PIM RP candidate using BSR. See “To Configure PIM RP Candidate”
