License Manager Overview
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
1117
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
TO INSTALL A LICENSE FILE
After issuing the command, the system displays the messages
• if the file was successfully installed
• status of individual licenses present in the file: valid, currently invalid (expired or
not effective yet), corrupted, not issued for this chassis or already installed
(duplicate).
If the file being installed already exists in the system, then the following message
is displayed:
ALU(config)# license install user:
License name: serial.xml_org
License already exists, for reinstallation remove
existing license
EXAMPLE
A) This is an example of installing a license file named testipsec5740.lic from a
remote location through FTP, and the file is installed successfully.
ALU(config)# license install ftp:
Address name of remote host [50.0.0.2]?
Remote Port [ Enter for default ] :
Source Path/File [/tftpboot/testipsec5740.lic]? /home/testuser/
testipsec5740.lic
Username [anonymous]? testuser
Password []?
License file downloaded successfully.
1. License for feature IPSEC installed successfully.
* Issued on : Thu Aug 21 11:53:20 2008
* Chassis ID: WL0537000214
* Serial num: 3
* Details : IP Security Encryption
* Attributes: Name Value
-------- -------
VALIDITY UNLIMITED
Command (in CM) Description
license install
{fpkey:|ftp:|http:|https:|tftp
:|user:|vrf <vrf-name>}
This command is used to install a license
file from the given location. The license
file can be obtained from the user area
or fpkey: (from the front panel USB), or it
can be obtained from a remote site using
FTP, TFTP, HTTP, HTTPS or through an
interface associated with the specified
VRF.
