IGMP Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
627
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
IGMP CONFIGURATION
This section includes the following:
• “IGMP Configuration Steps”
• “IGMP Configuration Flow”
• “IGMP Configuration Commands”
• “Show Commands in IGMP”
IGMP CONFIGURATION STEPS
The steps given below helps in configuring IGMP routing on the OmniAccess
5740 USG.
Step 1: Configure an interface. Enter Interface Configuration Mode.
ALU(config)# interface <name>
Example:
ALU(config)# interface GigabitEthernet3/0
ALU(config-if GigabitEthernet3/0)#
Note: IGMP can be configured on Layer 3 interfaces.
Step 2: Administratively bring up the interface
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if GigabitEthernet3/0)# no shutdown
Step 3: Configure IP address for the interface
ALU(config-if <interface-name>)# ip address {<ip-
address subnet-mask>|<ip-address/prefix-length>}
Example:
ALU(config-if GigabitEthernet3/0)# ip address
20.20.20.20/24
Step 4: Enable Multicast routing. See “To Enable Multicast Routing”
Step 5: Enable IGMP on an interface:. See “To Enable IGMP on an Interface”
