Alcatel-Lucent OmniAccess 5740 Cli Configuration Guide

Bridging Configuration
Left running head:
Chapter name (automatic)
426
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
BRIDGING CONFIGURATION ON PPP/MLPPP/FR/MLFR/HDLC/
G
IGE INTERFACE
Refer to the following sections to configure bridging on OmniAccess 5740 USG:
• “Bridging Configuration Steps”
• “Bridging Configuration Flow”
• “Bridging Configuration Commands”
BRIDGING CONFIGURATION STEPS
Note: The following bridging configuration commands are shown for a serial (V.35/X.21/RS-
232) interface having PPP encapsulation as an example. The steps are similar for
bridging configuration on MLPPP/FR/MLFR/HDLC interface and GigE interface as
well.
The given steps are similar for bridging configuration on T1 or an E1 interface having
MLPPP/FR/MLFR/HDLC encapsulation, and Gigabit Ethernet interface.
Refer to the “Point-to-Point Protocol”, “Multilink Point to Point Protocol”, “Frame
Relay”, “High-level Data Link Control”, “Ethernet Interfaces on SE”, “Universal Serial
Port (USP) Line Card”, “T1E1 Line Card” chapters for interface specific commands.
Step 1: Enter the Configuration Mode
ALU# configure terminal
ALU(config)#
Step 2: Configure Serial Interface
ALU(config)# interface Serial <slot/port>
ALU(config-if Serial<slot/port>)#
Example:
ALU(config)#interface Serial 0/0
ALU(config-if Serial0/0)#
Step 3: Administratively bring up the interface
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if Serial0/0)# no shutdown
