ROUTER CONFIGURATION MODE (RCM)
From the CM, you can enter the Router Configuration Mode (RCM). In this mode,
you can enter into any specific application by entering the corresponding name
such as OSPF, BGP, RIP, IP NAT, IP filter, firewall, etc.
Router configuration mode is used for configuring all the routing protocols.
E
XAMPLE
ALU(config)# router ospf 42
ALU(config-router ospf 42)#
EXITING CONFIGURATION MODES
You can exit from the current configuration session by typing End, Ctrl-C, Ctrl-Z
and return to the UM mode. You can use the Exit command in any configuration
mode to return to the previous configuration mode.
E
XAMPLE
ALU# configure
Enter configuration commands, one per line. End with CNTL/Z.
ALU(config)# interface GigabitEthernet 3/0
ALU(config-if GigabitEthernet3/0)# ^Z
ALU#
Command (in CM) Description
router bgp <1-65535> Enters BGP router configuration mode.
router ospf <1-65535> Enters OSPF router configuration mode.
router rip Enters RIP router configuration mode.
ip filter <name> Enters Filter configuration mode.
ip nat <name> Enters NAT configuration mode.
Command (in CM) Description
end
or
^Z
^C
Ends the current configuration session (from any
configuration mode) and returns to SUM.
exit Exits the current configuration mode and returns to the
preceding mode. For example, you can enter this
command to exit from CM to SUM or from ICM to CM.
top This command enables you to return to CM from the mode
you are currently in. For example, if this command is
entered in the ICM, control moves to the CM.
