Alcatel-Lucent OmniAccess 5740 Cli Configuration Guide

PVST+ Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
207
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
SHOW COMMANDS IN PVST+
TO VIEW A BRIEF CONFIGURATION OF PVST+
E
XAMPLE 1
ALU# show spanning-tree brief vlan 1
VLAN1
Spanning tree enabled protocol IEEE
ROOT ID Priority 32768
Address 00.07.50.0c.a1.00
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Bridge ID Priority 32768 Address 00.11.8b.00.27.12
Hello Time 2 sec Max Age 20 sec Forward Delay 15 sec
Port Designated
Name Port ID Prio Cost sts Cost Bridge ID Port ID
-------------- ------- ---- ---- --- ---- ----------------
switchport0/0 128.8 128 4 FWD 0 00.07.50.0c.a1.00 128.13
switchport0/1 128.7 128 4 DIS 0 00.11.8b.00.27.12 128.7
switchport0/2 128.6 128 4 DIS 0 00.11.8b.00.27.12 128.6
switchport0/3 128.5 128 4 DIS 0 00.11.8b.00.27.12 128.5
switchport0/4 128.4 128 4 DIS 0 00.11.8b.00.27.12 128.4
switchport0/5 128.3 128 4 DIS 0 00.11.8b.00.27.12 128.3
switchport0/6 128.2 128 4 DIS 0 00.11.8b.00.27.12 128.2
switchport0/7 128.1 128 4 DIS 0 00.11.8b.00.27.12 128.1
TO VIEW SUMMARIZED PVST+ DETAILS
EXAMPLE 1
ALU# show spanning-tree summary
Name Blocking Listening Learning Forwarding STP Active
--------- -------- --------- -------- ---------- ----------
VLAN1 7 0 0 1 8
VLAN2 0 0 0 1 1
VLAN3 0 0 0 1 1
--------------- -------- --------- -------- ----------------
3 VLANs 7 0 0 3 10
Command (in SUM/CM) Description
show spanning-tree brief [vlan
<1-4094>]
This command displays the spanning
tree configuration details in brief.
Command (in SUM/CM) Description
show spanning-tree summary This command displays the summary of
the spanning tree information.
