T1 Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
273
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
T1 CONFIGURATION
Refer to the following sections to configure a T1 line card on your OmniAccess
5740 USG:
• “T1 Configuration Steps”
• “T1 Configuration Flow”
• “T1 Configuration Commands”
• “T1 Show Commands”
• “Troubleshooting T1 Lines”
T1 CONFIGURATION STEPS
Following are the steps to configure T1 interface:
Step 1: Set the card type to T1 ““To Set the Card type to T1”
Step 2: Enter Controller Configuration Mode. See “To Configure T1 Controller”
Step 3: Configure channel-groups on the controller before entering into interface
configuration mode. See “To Configure Channelized T1”. This command creates a
channel-group that will form a channelized serial interface.
Step 4: Administratively bring up the T1 controller. See “To Bring Up/Shutdown
the T1 Controller”
Step 5: Configure Optional parameters for T1. See “Configure Optional
Parameters for T1 Controller”
• Configure cablelength. See “To Configure a Short Cablelength”, “To
Configure a Long Cablelength”
• Configure framing. See “To Configure Framing on T1”
• Configure linecoding scheme. See “To Configure Linecoding on T1”
• Configure clocksource. See “To Configure Clocksource”
Step 6: Enter Interface Configuration Mode to configure the channelized serial
interface. See “To Configure a Serial Interface”
Note: Creation of a channel-group is a pre-requisite prior to configuring a serial interface.
