Alcatel-Lucent OmniAccess 5740 Cli Configuration Guide

Destination NAT Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
697
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
DNAT CONFIGURATION STEPS
This section lists the steps to be followed while configuring DNAT.
Step 1: Configure the match-lists with the common classifiers pre-configured.
(Refer the “Common Classifiers” in this guide.)
Step 2: Enter the NAT Configuration Mode. See “To Enter NAT Configuration
Mode”
Step 3: Configure DNAT with host IP address or address pool See “To Configure
DNAT”
Step 4: Configure DNAT optional parameters.
• Configure port number for DNAT. See “To Configure Port Number for
DNAT”
• Configure Static DNAT. See “To Configure Static DNAT”
• Reorder the rules in the match-list for the configured DNAT. See “To
Reorder the Rules in DNAT”
Attach configured DNAT to an Interface
Step 5: Enter into Interface Configuration Mode
ALU(config)# interface <name>
Example:
ALU(config)# interface GigabitEthernet3/0
ALU(config-if GigabitEthernet3/0)#
Step 6: Administratively bring up the interface
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if GigabitEthernet3/0)# no shutdown
Step 7: Configure IP address for the interface
ALU(config-if <interface-name>)# ip address {<ip-
address subnet-mask>|<ip-address/prefix-length>}
Example:
ALU(config-if GigabitEthernet3/0)# ip address
20.20.20.20/24
