SNAT CONFIGURATION STEPS
This section lists the steps to be followed while configuring SNAT.
Step 1: Configure the match-lists with the common classifiers pre-configured.
(Refer the “Common Classifiers” in this guide)
Step 2: Enter the NAT Configuration Mode. See “To Enter NAT Configuration
Mode”
Step 3: Configure SNAT. See “To Configure SNAT”
Step 4: Configure SNAT optional parameters.
• Configure SNAT with host IP address. See “To Configure SNAT with Host
IP Address”
• Configure address pool. See “To Configure SNAT with an IP Address
Pool”
• Configure port range. See “To Configure SNAT with Port Range”
• Configure Static SNAT. See “To Configure Static SNAT”
• Reorder the rules in the match-list for the configured SNAT. See “To
Reorder the Rules in SNAT”
Attach configured SNAT to an Interface
Step 5: Enter into Interface Configuration Mode
ALU(config)# interface <name>
Example:
ALU(config)# interface GigabitEthernet3/0
ALU(config-if GigabitEthernet3/0)#
Step 6: Administratively bring up the interface
ALU(config-if <interface-name>)# no shutdown
Example:
ALU(config-if GigabitEthernet3/0)# no shutdown
