Virtual Router Redundancy Protocol
Left running head:
Chapter name (automatic)
158
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
VRRP CONFIGURATION SCENARIO USING OMNIACCESS 5740
USG
The topology consists of the following components:
• OmniAccess 5740 USG
• Alcatel-Lucent OmniSwitch
• Switch
• PC/Laptop
Figure 3: VRRP Topology
PROCEDURE
Configure LAN stations (192.168.1.4, 192.168.1.5, 192.168.1.6) with default
gateway address of 192.168.1.3, which is IP address of Virtual Router.
