Routing Information Protocol
Left running head:
Chapter name (automatic)
538
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
RIP OPTIONAL PARAMETERS
The following commands are the important but optional configuration commands
for RIP v1 and v2.
T
O SPECIFY A RIP VERSION
EXAMPLE
ALU(config-router rip)# version 1
ALU(config-router rip)# no version
Command (in RCM) Description
version {1|2}
This command is used to configure RIP
version - v1/v2 on the OmniAccess 5740
USG.
Configure RIP version to v1 to send and
receive only RIPv1 messages, and
configure RIP version to v2 to send and
receive only RIPv2 messages.
Note: RIPv2 is an enhancement of
RIPv1 and not a separate
protocol.
By default, RIP process
configured on OmniAccess
5740 USG system sends only
RIPv1 messages but receives
both RIPv1 and RIPv2
messages.
no version
This command resets the configured routing
protocol version.
