TO CONFIGURE IPSEC CRYPTO MAP
Crypto map entries created for IPsec pull together various parts used to set up
IPsec security associations that include:
• Which traffic should be protected by IPsec (as defined by match-list earlier)
• Where the IPsec-protected traffic should be sent (remote IPsec peer).
• What kind of IPsec security to be applied to this traffic (as configured by the
transform-set)
• Security associations established via IKE.
Note: The crypto map name can have a maximum of 32 characters.
Force - This option is used to modify a crypto map when it is applied to an interface.
EXAMPLE
ALU(config)# crypto map exampleMap ipsec-ike examplePolicy
ALU(config-crypto-map-exampleMap)#
T
O ATTACH MATCH-LIST TO A CRYPTO MAP
Note: If you try to attach a match-list to a crypto map that already has one, it overrides the
existing match-list provided it satisfies the match-list criteria for IPSec.
E
XAMPLE
ALU(config-crypto-map-exampleMap)# match matchlist1
ALU(config-crypto-map-exampleMap)# no match matchlist1
Command (in CM) Description
crypto map <name> ipsec-ike <ike-
policy name>} [force]
This command creates a crypto
map, and attaches an IKE policy to
it.
Enter the IKE policy name as
‘default’ to use the default IKE
policy.
Command (in Crypto Map CM) Description
match <match-list name> This command attaches a match-list to
a crypto map.
no match <match-list name> The ‘no’ command detaches the
specified match-list attached to a
crypto map.
