S
UB-INTERFACE CONFIGURATION MODE (S-ICM)
From the CM, you can enter Sub-Interface Configuration Mode (S-ICM), which is
a sub-mode of the ICM.
E
XAMPLE
The following command configures a sub-interface on Gigabit Ethernet interface:
ALU(config)# interface GigabitEthernet 3/0:1
ALU(config-subif GigabitEthernet3/0:1)#
The following command configures a sub-interface on a serial (V.35/X.21/RS-232)
interface:
ALU(config)# interface Serial0/0.1
ALU(config-if Serial0/0.1)#
The following command configures a sub-interface on a channelized serial
interface:
ALU(config)# interface Serial 0/0:0.1
ALU(config-if Serial0/0:0.1)#
To exit from the S-ICM and return to the ICM, use the Exit command. To end your
configuration session and return to SUM mode, press Ctrl-Z or enter the End
command.
Command (in CM) Description
interface <name> <slot/
port::subinterface-id>
This command enables you to configure
a sub-interface on a Gigabit Ethernet
interface. This enters the S-ICM.
The range for sub-interface is 1 to 4094.
interface <name> <slot/
port>.subinterface-id>
This command enables you to configure
a sub-interface on a Serial (V.35/X.21/
RS-232) interface. This enters the S-
ICM.
The range for sub-interface is 0-15.
Note: This is valid only if Frame
Relay encapsulation is set
on the main interface.
interface Serial <slot/
port:channel.subchannel>
This command enables you to configure
a sub-interface on a channelized Serial
interface (if the encapsulation on the
serial interface is set to Frame Relay).
This enters the S-ICM.
The range for sub-interface is 0-15.
