L2 Switching Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
183
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
• Configure L2 interface to operate in Trunk Mode:
Step 1: Configure L2 interface to Trunk mode. See “To Configure Mode for
the L2 Interface”
Step 2: Configure tagged VLANs that will be allowed when the interface is
configured to Trunk mode. See “To Configure Trunk VLAN”
Step 3: Configure range of VLANs that will be allowed when the interface is
configured to Trunk mode. See “To Configure Range of VLANs in Trunk
Mode”
OR
• Configure L2 interface to operate in Hybrid Mode:
Step 1: Configure L2 interface to Hybrid mode. See “To Configure Mode for
the L2 Interface”
Step 2: Configure tagged VLANs that will be allowed when the interface is
configured to Hybrid mode. See “To Configure Trunk VLAN”
Step 3: Configure Native VLAN (untagged VLAN). See “To Configure Hybrid
Native VLAN”
Step 5: Configure optional parameters on the interface.
• Configure Duplex Operation on the interface. See “To Configure Duplex
Operation”
• Configure Speed on the interface. See “To Configure Speed”
Step 6: Monitor and troubleshoot the configuration using the “show” commands.
See “L2 Switching Show Commands”
Step 7: Use the clear command to clear the MAC address table entries. See “L2
Switching Clear Commands”
