QoS Configuration
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
1019
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
TO VIEW AUTO QOS CONFIGURATION
EXAMPLE
ALU(config)# show auto qos diff-serv
auto qos diff-serv
class autoqos-class-af1
match ip any any dscp af11
match ip any any dscp af12
match ip any any dscp af13
bandwidth percent 20
queue-limit 350
random detect ip-dscp af11 min-threshold 200 max-threshold 300
random detect ip-dscp af12 min-threshold 150 max-threshold 300
random detect ip-dscp af13 min-threshold 100 max-threshold 300
random-detect ip-dscp
class autoqos-class-af2
match ip any any dscp af21
match ip any any dscp af22
match ip any any dscp af23
bandwidth percent 20
queue-limit 350
random detect ip-dscp af21 min-threshold 200 max-threshold 300
random detect ip-dscp af22 min-threshold 150 max-threshold 300
random detect ip-dscp af23 min-threshold 100 max-threshold 300
random-detect ip-dscp
class autoqos-class-af3
match ip any any dscp af31
match ip any any dscp af32
match ip any any dscp af33
bandwidth percent 20
queue-limit 350
random detect ip-dscp af31 min-threshold 200 max-threshold 300
random detect ip-dscp af32 min-threshold 150 max-threshold 300
random detect ip-dscp af33 min-threshold 100 max-threshold 300
random-detect ip-dscp
class autoqos-class-af4
match ip any any dscp af41
match ip any any dscp af42
match ip any any dscp af43
bandwidth percent 20
queue-limit 350
Command (in SUM/CM) Description
show auto qos {<interface-
name> [diff-serv|voip]|diff-
serv|statistics [<interface-
name>]|voip}
This command displays all/any Auto
QoS configuration.
You can view the Auto QoS configuration
for a specific interface.
The output of this command is a list of all
the Auto QoS policies, and traffic
classes.
This command also displays the Auto
QoS statistics on all the interfaces or a
specific interface.
