IPsec Interoperability of OmniAccess 5740 USG
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
23
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Appendix E IPsec Interoperability of
OmniAccess 5740 USG
CONFIGURING IPSEC TUNNEL BETWEEN OMNIACCESS 5740
USG
AND VPN FIREWALL BRICK
The following scenario explains how to establish a IPsec tunnel between the
OmniAccess 5740 USG and VPN Firewall Brick.
Topology:
Figure 67: IPsec Interoperability Between OmniAccess 5740 USG and VPN
Firewall Brick
The test network consists of VPN Firewall Brick running a crypto image. The
IPsec tunnel is created for the host 10.91.10.2/24 and 192.168.60.18/24 to
communicate in a secure manner.
