Alcatel-Lucent OmniAccess 5740 Cli Configuration Guide

Multilink Frame Relay
Left running head:
Chapter name (automatic)
394
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Alcatel-Lucent
ALU# show mlfr 1
MLFR bundle 1 link state information:
MEMBER LINKS PROTOCOL STATE BID LID
Serial0/1:1 UP mlfr1 Serial0/1:1
Serial0/0:1 UP mlfr1 Serial0/0:1
ALU# show interfaces Serial 0/0:1
Serial0/0:1 is up, line protocol is up
Internet address not set
MTU 1500 bytes, BW 1536 Kbit, DLY 0 usec,
reliability 255/255, txload 0/255, rxload 0/255
Loopback not set
Encapsulation mlfr, MLFR Bundle Id: 1
Hello Interval: 10(secs)
Ack-interval :4(secs), Max Retry count :3
Link state : UP
Statistics:
Current Retry Count is 0
Add_link_sent:4, Add_link_rcvd:1
Add_link_ack_sent:1, Add_link_ack_rcvd:2
Rm_link_sent:0, Rm_link_rcvd:0
Rm_link_ack_sent:0, Rm_link_ack_rcvd:0
Hello_sent:55, Hello_rcvd:56
Hello_ack_sent:56, Hello_ack_rcvd:55
Last input never, output never, output hang never
Last clearing of "show interface" counters never
Queueing strategy: fifo
Output queue: 0/0 (size/max) 0 drops; Input queue: 0/0 (size/max) 0 drops
Conversations: 0/0/0/0 (active/max active/max total)
Reserved Conversations: 0/0 (allocated/max allocated)
Available Bandwidth 1536 kilobits/sec
5 minute input rate 24 bits/sec, 0 packets/sec
5 minute output rate 24 bits/sec, 0 packets/sec
1237 packets input, 32681 bytes, 0 no buffer
Received 0 broadcasts, 0 runts, 0 giants, 0 throttles
0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort
1249 packets output, 49735 bytes, 0 underruns
0 output errors, 0 collisions, 16 interface resets
0 output buffer failures, 0 output buffers swapped out
18 carrier transitions
Timeslot(s) Used:1-24 (64Kbps each), Transmitter delay is 0 flags
Note: All the show commands that take IP interface name as an argument will also take
MLFR interface as a parameter.
