LFI Configuration on FR
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
465
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
TO VIEW FRAGMENTATION AND REASSEMBLY STATISTICS
EXAMPLE
ALU(config)# show frame-relay fragments
Interface serial 1/0:0
Frags: 90 fragmented, 34 couldn't fragment, 450 fragments created
Reass: 324 reassembled, 20 timeouts, 32 dropped, 25 reordered
Interface serial 1/1:0
Frags: 40 fragmented, 14 couldn't fragment, 250 fragments created
Reass: 24 reassembled, 10 timeouts, 8 dropped, 20 reordered
TO VIEW FRAGMENTATION AND REASSEMBLY STATISTICS PER VC
E
XAMPLE
ALU(config)# show frame-relay pvc
DLCI = 100, DLCI USAGE = LOCAL, PVC STATUS = STATIC, INTERFACE = Serial0/
0:0
…………
End-to-End Fragmentation Statistics
Packets fragmented 10
Fragments Created 220
fragments failed 0
End-to-End Reassembly Statistics
fragments received 220
fragments reassembled 220
fragments dropped 0
fragments timeout 0
fragments reordered 0
DLCI = 110, DLCI USAGE = LOCAL, PVC STATUS = STATIC, INTERFACE = Serial0/
0:0.1
…………
Command (in SUM/CM/ICM) Description
show frame-relay fragments Displays the fragmentation and
reassembly statistic for main interface.
Command (in SUM/CM/ICM) Description
show frame-relay pvc Displays the fragmentation and
reassembly statistic per PVC.
