Management Plane Overview
Except on the first page, right running head:
Heading1 or Heading1NewPage text (automatic)
53
Alcatel-Lucent
Beta Beta
OmniAccess 5740 Unified Services Gateway CLI Configuration Guide
Once the above fields are entered and ping is initiated, you will see the following
output:
!!!!! : Each exclamation point (!) denotes receipt of a reply. A
period (.) denotes that the network server has timed out while
waiting for a reply.
Success rate is 100 percent: Percentage of packets successfully
echoed back to the router. Anything less than 80 percent is
usually considered problematic.
round-trip min/avg/max = 2/4/5 ms: Round-trip travel time
intervals for the protocol echo packets, including minimum/
average/maximum (in milliseconds).
Set the df-bit value[n]: Specify whether or not the Don't
Fragment (DF) bit is to be set on the ping
packet.
If yes is specified, the Don't Fragment
option does not allow this packet to be
fragmented when it has to go through a
segment with a smaller Maximum
Transmission Unit (MTU), and you will
receive an error message from the
device that wanted to fragment the
packet. This is useful for determining the
smallest MTU in the path to a
destination. The default is no.
Set the ttl value[64]: Specify the Time to Live (TTL) value in
the range 1-255. The number of hops a
packet can have before it is discarded in
the network.
Each router reduces the TTL value by
one before forwarding it. It is a way of
making sure that the packets destined to
non-existing targets die out eventually.
Default is 64.
Field Description
