VNA Commands [:SENSe]:CORRection:COLLect Subsystem
MS20xxC PM PN: 10580-00306 Rev. E 3-125
The tables below list the connector and valid connector name that are
associated with the calibration line type COAX. Note that User cal kit
and Waveguide do not have a calibration name associated with them.
COAX
<connector> [connector-name] Description
NMALe OSLN50 N-Conn(M)
Cal Kit: OSLN50.
If no connector-name is given,
then connector will be set to this.
Query Response string: “NMAL”
NMALe SLN50A or
OSLN50A-8 or
OSLN50A-18
N-Conn(M)
Cal Kit: OSLN50A-8 or
OSLN50A-18
Query Response string:
“NMAL(OSLN50A-8 or
OSLN50A-18)”
NMALe TOSLN50A or
TOSLN50A-8 or
TOSLN50A-18
N-Conn(M)
Cal Kit: TOSLN50A-8 or
TOSLN50A-18
Query Response string:
“NMAL(TOSLN50A-8 or
TOSLN50A-18)
NFEMale OSLNF50 N-Conn(F)
Cal Kit: OSLNF50.
If no connector name is given,
then connector will be set to this.
Query Response string: “NFEM”
NFEMale OSLNF50A or
OSLNF50A-8 or
OSLNF50A-18
N-Conn(F)
Cal Kit: OSLNF50A-8 or
OSLNF50A-18
Query Response string:
“NFEM(OSLNF50A-8 or
OSLNF50A-18)”
NFEMale TOSLNF50A or
TOSLNF50A-8 or
TOSLNF50A-18
N-Conn(F)
Cal Kit: TOSLNF50A-8 or
TOSLNF50A-18
Query Response string:
“NFEM(TOSLNF50A-8 or
TOSLNF50A-18)”
KMALe OSLK50 K-Conn(M)
Cal Kit: OSLK50.
If no connector name is given,
then connector will be set to this.
Query response string: “KMAL”
