VNA Commands Trace Subsystem
MS20xxC PM PN: 10580-00306 Rev. E 3-161
TRACE_x_WINDOWING Windowing, where x is the trace number.
Available windowing settings are:
Rectangular = 0, Nominal Side Lobe = 1,
Low Side Lobe = 2, Minimum Side Lobe = 3
TRACE_x_GD_APERTURE Group Delay Aperture, where x is the trace
number.
TRACE_x_DSP_DATA_POINTS Number of data points, where x is the trace
number.
TRACE_x_LOG_MAG_RESOLUTION Log Mag Resolution, where x is the trace number.
Returned value is in dB.
TRACE_x_LOG_MAG_REFERENCE Log Mag Reference value, where x is the trace
number. Returned value is in dB.
TRACE_x_LOG_MAG_REFERENCE_LINE Log Mag Reference Line, where x is the trace
number.
TRACE_x_SWR_RESOLUTION SWR Resolution, where x is the trace number.
Returned value is 1000 times the SWR
Resolution.
TRACE_x_SWR_REFERENCE SWR Reference value, where x is the trace
number. Returned value is 1000 times the SWR
Reference value.
TRACE_x_SWR_REFERENCE_LINE SWR Reference Line, where x is the trace
number.
TRACE_x_PHASE_RESOLUTION Phase Resolution, where x is the trace number.
Returned value is 1000 times the phase
resolution.
TRACE_x_PHASE_REFERENCE Phase Reference value, where x is the trace
number. Returned value is 1000 times the phase
reference value.
TRACE_x_PHASE_REFERENCE_LINE Phase Reference Line, where x is the trace
number.
TRACE_x_REAL_RESOLUTION Real Resolution, where x is the trace number.
Returned value is 1000 times the
resolution per div value.
TRACE_x_REAL_REFERENCE Real Reference value, where x is the trace
number. Returned value is 1000 times the
reference value.
TRACE_x_REAL_REFERENCE_LINE Real Reference line, where x is the trace number.
TRACE_x_IMAG_RESOLUTION Imaginary Resolution, where x is the trace
number. Returned value is 1000 times the
reference value.
Table 3-12. Trace Header Parameters (Sheet 7 of 9)
Parameter Name Description
