Trace Subsystem VNA Commands
3-162 PN: 10580-00306 Rev. E MS20xxC PM
TRACE_x_IMAG_REFERENCE Imaginary Reference value, where x is the trace
number. Returned value is 1000 times the
reference value.
TRACE_x_IMAG_REFERENCE_LINE Imaginary Reference line, where x is the trace
number.
TRACE_x_GD_RESOLUTION Group Delay Resolution, where x is the trace
number. Returns in units of picoseconds.
TRACE_x_GD_REFERENCE Group Delay Reference value, where x is the
trace number. Returns in units of picoseconds.
TRACE_x_GD_REFERENCE_LINE Group Delay Reference line, where x is the trace
number.
TRACE_x_SMITH_SCALE Currently not used.
TRACE_x_SMITH_IMPEDANCE Currently not used.
TRACE_x_SMITH_IMPEDANCE_LINE Currently not used.
TRACE_x_1PCL_RESOLUTION Log Mag/2 resolution, where x is the trace
number. Returned value is in dB.
TRACE_x_1PCL_REFERENCE Log Mag/2 Reference value, where x is the trace
number. Returned value is in dB.
TRACE_x_1PCL_REFERENCE_LINE Log Mag/2 Reference line, where x is the trace
number.
TRACE_x_POLAR_RESOLUTION Currently not used.
TRACE_x_POLAR_REFERENCE Currently not used.
TRACE_x_POLAR_REFERENCE_LINE Currently not used.
CAL_METHOD Calibration Method, where:
SOLT = 0, SSLT = 1, and SSST = 2.
CAL_TYPE The index of the selected calibration type list,
where 0 is the first in the list.
CAL_LINE_TYPE Calibration Line Type, where coax = 0.
CAL_PORTx_DUT The index of the selected Calibration Coax DUT
Selector list for port x, where 0 is the first in the
list.
CAL_CORRECTION Calibration correction, where On = 0, and Off = 1
APP_SELF_TEST_MODE Internal use only
DEBUG_MEAS_GAIN_RANGE Internal use only
LOG_COUNTER_EVENTS Internal use only
SWEEP_DEFAULT_FREQS Internal use only
PWRCAL_RF_SWITCH_FREQ Internal use only
PWRCAL_LOW_RF_HIGH_TARGET Internal use only
Table 3-12. Trace Header Parameters (Sheet 8 of 9)
Parameter Name Description
