:TRACe Subsystem Spectrum Analyzer Commands
6-56 PN: 10580-00306 Rev. E MS20xxC PM
TRACE_B_VIEW_NOT_BLANK:
0x0000000000010000
TRACE_B_WRITE_NOT_HOLD:
0x0000000000020000
TRACE_B_DATA_VALID:
0x0000000000040000
TRACE_C_VIEW_NOT_BLANK:
0x0000000100000000
TRACE_C_WRITE_NOT_HOLD:
0x0000000200000000
TRACE_C_DATA_VALID:
0x0000000400000000
TRACE_C_IS_B_MINUS_A_ON:
0x0000001000000000
TRACE_C_IS_A_MINUS_B_ON:
0x0000002000000000
TRACE_COUNT Number of traces averaged
UI_DATA_POINTS Number of display points
IMPEDANCE Input impedance
REFERENCE_FREQUENCY Reference freq
SET_SWEEP_TIME Minimum sweep time setting
TRIGGER_TYPE Trigger type
VIDEO_TRIGGER_LEVEL Video trigger level
TRIGGER_POSITION Trigger position as a percent of the display
PEAK_THRESHOLD Marker peak search threshold
MARKER_TABLE Marker table status
ACTIVE_ MEASUREMENT Current measurement
ANTENNA Antenna index
OCC_BW_METHOD Occupied bandwidth method
OCC_BW_PERCENT Occupied bandwidth % of power setting
OCC_BW_DBC Occupied bandwidth dBc setting
OCC_BW_MEASURED_ DB Occupied bandwidth measured dBc value
OCC_BW_MEASURED_ PERCENT Occupied bandwidth measured % value
OCC_BW_VALUE Measured occupied bandwidth
OCC_BW_LINE_ MARKER_INFO Mask off 16 bits at a time to get the display
point location of the 3 OBW display indicators
CH_PWR_WIDTH Channel power integration bandwidth
CH_PWR_VALUE Measured channel power
CH_PWR_DENSITY Measured channel power density
CH_PWR_LINE_ MARKER_INFO Mask off 16 bits at a time to get the display
point location of the 2 channel power display
indicators
ACPR_MAIN_CH_BW ACPR main channel bandwidth
ACPR_ADJC_CH_BW ACPR adjacent channel bandwidth
ACPR_CHANNEL_ SPACING ACPR channel spacing
Table 6-2. Trace Header Parameters (Sheet 2 of 4)
Parameter Name Description
