Spectrum Analyzer Commands :TRACe Subsystem
MS20xxC PM PN: 10580-00306 Rev. E 6-57
ACPR_MAIN_CH_PWR ACPR measured main channel power
ACPR_UPPER_CH_PWR ACPR measured upper channel power
ACPR_LOWER_CH_ PWR ACPR measured lower channel power
ACPR_LOWER_CH_ LINE_MARKER_INFO Mask off 16 bits at a time to get the display
point location of the 2 ACPR lower channel
display indicators
ACPR_MAIN_CH_LINE_ MARKER_INFO Mask off 16 bits at a time to get the display
point location of the 2 ACPR main channel
display indicators
ACPR_UPPER_CH_ LINE_MARKER_INFO Mask off 16 bits at a time to get the display
point location of the 2 ACPR upper channel
display indicators
AM_FM_DEMOD_VOL AM/FM demod volume
AM_FM_DEMOD_ FREQUENCY AM/FM demod freq
AM_FM_DEMOD_TYPE AM/FM demod type
AM_FM_DEMOD_TIME AM/FM demod time
AM_FM_LINE_ MARKER Display point location of the demodulation
frequency
BEAT_FREQUENCY_ OSC_FREQUENCY BFO oscillator freq
CI_C_TYPE C/I measurement carrier type
CI_C_VALUE C/I measurement measured carrier power
CI_I_BB_VALUE C/I measurement measured broadband
interference power
CI_I_NB_VALUE C/I measurement measured narrowband
interference power
CI_I_WB_VALUE C/I measurement measured wideband
interference power
CI_BB_VALUE C/I measurement with broadband interference
CI_NB_VALUE C/I measurement with narrowband interference
CI_WB_VALUE C/I measurement with wideband interference
MKR_SPA_FREQNx Marker x frequency (where x is the marker
number 0-11, 0 represent the reference marker
#1 and 1 represent delta marker #1, 2
represent reference marker #2, and 3
represent delta marker #2, and so on)
MKR_SPA_POINTx Reference marker x display point
MKR_SPA_MAGNTx Reference marker x magnitude
MKR_SPA_PRCNTx Reference marker x display percentage
MKR_SPA_FLAGSx Reference marker x flags:
Table 6-2. Trace Header Parameters (Sheet 3 of 4)
Parameter Name Description
