SAW sensor – Parameter
Type 8098 FLOWave L
15.7.5 Deactivating the damping of the liquid concentration values
By default, the liquid concentration values are not damped.
But if the damping of a liquid concentration value (Concentration1 or Concentration2) is active, do the fol-
lowing to deactivate it:
→ Go to the CONFIGURATION view.
→ SAWsensor
→ Parameter view.
→ Add.meas.values
→ Concentration1 or Concentration2
→ Damping The Currentsettings are displayed
→ None The Newsettings are displayed.
→
The damping of the liquid concentration value is inactive.
15.7.6 Activating the monitoring of the liquid concentration
Because of a malfunction in the process, the measured liquid concentration value can be too high or too
low.
A monitored value can be:
• in the normal operating range.
• in the warning range,
• in the error range.
You can set 4 limit values: 2 error limits and 2 warning limits.
→
of the liquid concentration.
in
and if the monitored value increases or decreases.
By default, the monitoring of the liquid concentration and the diagnostics are all disabled.
To activate the monitoring of a liquid concentration value, do the following:
→ Go to the CONFIGURATION view.
→ SAWsensor
→ Parameter view.
→ Add.meas.values
