Installation in the pipe
Type 8098 FLOWave L
7.5.4 Installing a device with external-threaded connections
according to DIN11851 seriesA for pipes according to
DIN11850
To install this device variant, respect the mounting standards that are applicable to the process.
→ Supply the following accessories that are not delivered by the device manufacturer. The accessories
must be adapted to the process and to the device:
• 2 round slotted nuts
• 2 conical ferrules
• 
-
lowing type:
 
 

Installationprocedure:
 Put the round slotted nuts on the pipe. Respect the mounting direction of the round slotted nuts so that
.
Conical ferrule
Gasket
Round slotted nut
Pipe

 
2. Weld the conical ferrules to the pipe.
3. 
mounting direction of the gaskets.
4. Screw the round slotted nuts and tighten them according to the mounting standards that are applicable
to the process.
