Electrical installation
Type 8098 FLOWave L
8.5 Activating the device internal termination resistor
The device has an internal termination resistor that can be activated if the device is installed at one end of a
büS network or of a CANopen network.
If you activate the device internal termination resistor, do not install more than one termination resistor at the
same end of the büS network or of the CANopen network.
To have an adapted network, connect one termination resistor at each end of the network.
To activate the device internal termination resistor, do the following:
→ Go to the CONFIGURATION view.
→ Generalsettings
→ Parameter view.
→ büS
→ Advanced
→ Terminationresistor
→ On
→ 
The internal termination resistor is activated.
8.6 Specications of the cables for the M20x1.5 cable
glands (device variant with cable glands)
 
Specicationofthecables Recommendedvalue
 Shielded
Diameter 
 
 
Specicationofthecables Recommendedvalue
 Shielded
Diameter 
 
