44
Installation in the pipe
Type 8098 FLOWave L
For safety reasons and to comply with standard
or the Wi-Fi module are locked.
→ Prepare the unlocking magnetic key, which is
delivered with the device.
The blind cover or the display module or the Wi-Fi
module is locked
Put the magnetic key on the
mark related
to the display module or the Wi-Fi module. You
should hear a soft click indicating that the display
module or the Wi-Fi module is unlocked. Do not
use a tool to turn the display module or the Wi-Fi
module.
2. While the magnetic key is on the mark,
turn the display module or the Wi-Fi module
by hand only from the locked position to the
unlocked position. If you cannot turn the display
module or the Wi-Fi module by hand, contact
Bürkert.
The display module or the Wi-Fi module is
unlocked
3. Carefully lift the display module or the Wi-Fi
module because a cable connects the display
module or the Wi-Fi module to the transmitter.
4. Push the tab of the cable connector to dis-
connect the display module or the Wi-Fi module
from the transmitter.
Remove the display module or the Wi-Fi module
and put it on a clean surface to protect the seal
from dirt.
Push the tab to
unlock the cable
connector
English
