WindO/I-NV4 User’s Manual 23-7
1 Overview
23
User Accounts and the Security Function
● Operations Subject to Password Protection
If you configure a password for a user account assigned to a security group to protect access to data, access to data
is password protected. The operations that are subject to password protection and the security group that the
password is valid for are as follows.
*1 Switch between Permitted and Prohibited in the Security Settings dialog box.
*2 USB flash drive inserted in USB1 for HG2J-7U, SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F, USB flash
drive for HG2G-5T and HG1G/1P
*3 SD memory card for HG5G/4G/3G/2G-V, HG4G/3G and HG2G-5F, USB flash drive for HG2G-5T and HG1G/1P
*4 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F/-5T, HG1G/1P only
*5 HG2J-7U only
*6 HG5G/4G/3G/2G-V, HG4G/3G, HG2G-5F only
*7 It depends on the settings in Security Settings dialog box. For details, refer to “Web Page Tab” on page 23-42.
Operations subject to password protection
Security group that the password is valid for
Administrator Operator Reader User-created
Data editing Opening projects YES NO NO
YES
*1
Modifying
data
Downloading a project data YES NO NO
YES
*1
Uploading a project data YES NO NO
YES
*1
Delete data stored in the internal memory YES NO NO NO
Downloading files to an external memory device
*2
YES NO NO NO
Uploading files from an external memory device
*2
YES YES YES NO
Downloading files to an external memory device
*2
while the MICRO/I is running
YES YES NO NO
Downloading PLC programs from an external
memory device to external devices
YES NO NO NO
Uploading PLC programs from
external devices
to an
external memory
device
YES NO NO NO
Deleting files in external memory device
*2
YES NO NO NO
Formatting
*4
external memory device
*3
YES NO NO NO
Copying files to a USB1
*5
YES YES NO NO
Copying files to a USB2
*5
YES YES YES NO
Copying files to an SD memory card
*6
YES YES NO NO
Copying files to a USB flash drive
*6
YES YES YES NO
Switching to the System Mode YES NO NO NO
Use Monitor Function in WindO/I-NV4 or Device
Monitor
YES YES NO NO
Remotely monitoring the MICRO/I state from a
web browser terminal
YES YES YES NO
Remotely operating the MICRO/I state from a web
browser terminal
YES YES NO NO
Displaying and operating the Custom Web page of
the MICRO/I from a web browser terminal
*7 *7 *7 *7
• You can set a dedicated password. In the Security dialog box, on the Options tab, select the Use
Password to open a Project check box, and then set the password. The dedicated password is
applicable to the following operations:
- Opening projects
- Reusing screens
- Opening projects after uploading project data
• To password protect operations, the lowest level security group out of the security groups enabled with a
password must be assigned to a user account.
The security levels, from highest to lowest, are Administrator > Operator > Reader.
Example: To password protect the operation to display Device Monitor, assign the Operator security
group to a user account. If a user account assigned to the Operator security group does not
exist, the operation is not password protected.
• The commands that the USB Autorun function can execute vary based on the enabled security group. For
details, refer to Chapter 31 “2.4 USB Autorun Function Security” on page 31-34.
