NEC Xen Master Programming Manual

May 2003
Programming Manual 1 - 19
A6-324000-642-02 - Release 6.0 May 2003
31 Hold Tone Source Selection Internal Internal or External
32 Hold Internal Tone Volume Selection 0 dB 0 dB, -6 dB
33 Master Clock Selection Cabinet No. = 0
(No Assign)
Cabinet: 0~3
Slot: 1~8
35 COM Port Baud Rate Setting
Assignment
COM 1: 38.4 Kbps
COM 2: 4.8 Kbps
COM 3: 4.8 Kbps
COM 4: 9.6 Kbps
COM 1~4: 4.8 Kbps, 9.6 Kbps, 19.2 Kbps,
38.4 Kbps
36 COM Port Parity/Stop Bit Setting
Assignment
COM 1~4: None/1 COM 1~4: None/1, None/2, Even/1, Odd/1
37 General Purpose Relay Assignment No Yes = Assigned, No = Not Assigned
38 Modem Port for Remote Programming
Assignment
Not Specified Station No.
2 Digit = 00~99
3 Digit = 000~999
4 Digit = 0000~9999
40 ACD Hunt Timer 10 sec. 10 sec., 20 sec., 30 sec., 60 sec., 120 sec.,
240 sec., No Limit.
47 CAR for Voice Mail Message Notice
Assignment
Not Specified Any unused CAR
LK 1 System Mode
LK 8 PBR/Miscellaneous (Continued)
Data
No.
Memory Block Name Default Value Programming Values
LK 1 System Mode
LK 9 DISA
Data
No.
Memory Block Name Default Value Programming Values
00 DISA/ID Code Assignment Refer to DISA/ID Code Assignment on page 1-229.
02 DISA/ID Password Effect/Invalid
Selection
DISA Password Effect
(Yes)
DISA Password Invalid (No)
DISA Password Effect (Yes)
LK 1 System Mode
LK 11 (Not Used)
