NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 20 Multiline Terminal Programming
A6-324000-642-02 - Release 6.0
May 2003
LK 1 System Mode
LK 12 ACD/UCD
Data
No.
Memory Block Name Default Value Programming Values
00 ACD/UCD Group Pilot Number
Assignment
Not Specified Tel No. (Up to 4 digits)
(for each ACD/UCD Group No. 1~4)
01 ACD/UCD Group Overflow Destination
Assignment
Not Specified Tel No. (Up to 4 digits)
(for each ACD/UCD Group No. 1~4)
02 ACD/UCD Overflow Timer Selection 60 sec. ∞, 10 sec., 20 sec., 30 sec., 60 sec.,
120 sec., 180 sec., 240 sec.
(for each ACD/UCD Group No. 1~4)
LK 1 System Mode
LK 13 PRI/ISDN
Data
No.
Memory Block Name Default Value Programming Values
00 PRI ISDN Channel Number Selection Refer to PRI ISDN
Channel Number
Selection on page 1-
239.
0, 4, 8, 12, 16, 20, 24, 28, 32
05 PRT B-Channel Map Assignment
LK 1 System Mode
LK 14 Automatic Route Selection
Data
No.
Memory Block Name Default Value Programming Values
00 ACR Feature Allow/Deny Selection No Yes (Allow), No (Deny)
01 ACR Dialling Assignment None Table No. 1~4
Dial No. 01~C8
Setting Data (8 digit Max) including 0~9), *,
#, X (0~9), *, #), P (0 or 1), or N (2~9)
02 ACR Dialled Number Dial Allow/Deny
Selection
Yes Yes (Allow), No (Deny)
03 ACR Route Table Number Assignment 00 Table No. 1~4
Dial No. 01~C8
Routes 01~32
04 ACR Trunk Group to Route Number
Assignment
Normal Normal, TKGP 01~32, ICM
05 ACR Digit Delete Assignment 00 00~10 Digits
06 ACR Digit Add Assignment Not specified Up to 10 digits using 0~9, *, #
