NEC Xen Master Programming Manual

May 2003
Programming Manual 1 - 425
A6-324000-642-02 – Release 6.0 May 2003
First Digit PBR
Release Timer
Selection
1-3-03 Specify the time that a receiver is
connected when a DTMF Single
Line Telephone user is dialling.
10 sec. 10 sec. 60 sec.
Hookflash Start Time
Selection
1-3-05 Specify a minimum hookflash
duration for a Single Line
Telephone to receive a second dial
tone.
40 ms. 290 ms. 790 ms.
Hookflash End Time
Selection
1-3-06 Specify a maximum duration from
a Single Line Telephone to receive
a second dial tone (HT = Hookflash
Start Time).
HST + 0 ms. HST + 700
ms.
HST + 1500
ms.
Voice Mail DTMF
Delay Timer Selection
1-3-08 Specify the delay time before
DTMF tones are sent to the VMI
port.
0 sec. 1 sec. 8 sec.
Voice Mail Disconnect
Time Selection
1-3-09 Specify the sending time of a
disconnect signal that is sent to the
connected equipment.
.5 sec. 1.5 sec. 3.5 sec.
Voice Mail DTMF
Duration/Interdigit
Time Selection
1-3-10 Specify the DTMF duration/
interdigit time for voice mail.
60/70 ms. 110/80 ms. 810/190 ms.
Tandem Transfer
Automatic Disconnect
Timer Selection
1-4-00 Specify a maximum time before
automatic disconnect of a Trunk-
to-Trunk transfer occurs.
30 min. 1 hr. 3 hr.
Tandem Transfer
Automatic Disconnect
Timer Selection*
1-4-00 Specify a maximum time before
automatic disconnect of a Trunk-
to-Trunk transfer occurs.
000 min. 060 min. 999 min.
Automated Attendant
First Digit PBR
Release Timer
Selection
1-4-01 Specify the PBR connection time
to the Automated Attendant trunk
to receive the DTMF signal from
the calling party before
automatically disconnecting.
5 sec. 20 sec. 60 sec.
Automated Attendant
Transfer Delayed
Ringing Time
Selection
1-4-02 Specify the time for a No Answer at
the transferred station before the
Automated Attendant rings a
predetermined station.
10 sec. No Limit No Limit
Automated Attendant
No Answer
Disconnect Time
Selection
1-4-03 Determine how long the
Automated Attendant rings a
station before dropping the call.
1 min. 2 min. 4 min.
Automated Attendant
Answer Delay Time
Assignment
1-4-13 Assign the number of seconds
before the Automated Attendant
answers an incoming CO/PBX call
when there is no answer.
0 sec. 4 sec. 99 sec.
Table 1-6 Function Timer Chart (Continued)
Timer
Memory
Block
Definition
Timing Value
Minimum Default Maximum
*Software Version 2.xx or higher
