NEC Business Solutions Ltd Xen Master & Xen Axis
1 - 432
A6-324000-642-02 – Release 6.0
May 2003
8-Digit Matching Table to Class Assignment
(Memory Block 1-1-61)
This Memory Block assigns the 8-Digit Matching Tables to the Code
Restriction Classes. The 8-Digit Matching Tables are also assigned as
Allow/Deny Tables in this Memory Block. Any combination of 8-Digit
Matching Tables (Allow, Deny, or Not Used) can be assigned to Code
Restriction Classes 01~14. Classes 00 and 15 are fixed and are non
programmable.
Code Restriction Class Allow/Deny Selection
(Memory Block 1-1-65)
This Memory Block assigns the Code Restriction Classes (01~14) as Allow
or Deny. This assignment is used when there is no match or when there is
an overlap (duplicate numbers in tables with opposite Allow/Deny
assignments) of number in the 8-Digit Matching Tables.
8-Digit Matching Table Operations
The 8-Digit Matching Tables are used to restrict specific or all OCC calls and
non-OCC calls. To understand the relationship of the 8-Digit Matching
Tables with OCC calls, refer to 6.4.2 - OCC Assignment/Operation.
When a restricted station user makes a non-OCC call, the system monitors
the first eight digits dialled and searches the 8-Digit Matching Tales assigned
for Used in Memory Block 1-1-66 (8-Digit Matching Table to Normal Dial
Assignment).
The system searches only the 8-Digit Matching Tables assigned to the Code
Restriction Class the station is assigned to and has the Trunk group
assigned to it for the in-use trunk the station is on.
If a match is found, the system looks at the 8-Digit Matching Table to Class
Assignment for the Allow or Deny Assignment. If the table is assigned as
Allow, the call is allowed. If the table is assigned as Deny, the call is denied.
If a match is not found or a duplicate match is made with opposite Allow/
Deny Assignments, the system looks at the class Allow/Deny Assignment. If
the class is assigned as Allow, the call is allowed. If the Class is assigned as
Deny, the call is denied. If the interdigit time of the dialling party exceeds 10
seconds while the station user is dialling on an outside line, and the system
is searching the assigned tables, the system automatically drops the call.
6.4.4 System Speed Dial Override by Class Selection
(Memory Block 1-1-62)
This Memory Block allows System Speed Dial buffers to override or not
override Code Restriction. Each Code Restriction Class (01~14) is assigned
as Allow or Deny.
6.4.5 Tie Line Code Restriction Assignment
(Memory Block 1-1-69)
This Memory Block assigns system-wide Code Restriction to be used or not
used for calls made on a Tie line.
6.4.6 Code Restriction Class Assignment When Lockout is Set
(Memory Block 1-1-70)
This Memory Block assigns the Code Restriction Class to be used when
Station Lockout (Outgoing) is set at a station. Station Lockout can be set by
the Attendant or from any station if allowed in System Programming.
