Date Code 20170927 Instruction Manual SEL-751 Relay
SET.21
of 78
Date _______________ SEL-751 Settings Sheets
SV/Timers Logic Settings (SET L Command)
SV/Timers
RST31 :=
SET32 :=
RST32 :=
SV TIMER PICKUP (0.00–3000.00 s) SV01PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV01DO :=
SV INPUT (SELOGIC) SV01 :=
SV TIMER PICKUP (0.00–3000.00 s) SV02PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV02DO :=
SV INPUT (SELOGIC) SV02 :=
SV TIMER PICKUP (0.00–3000.00 s) SV03PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV03DO :=
SV INPUT (SELOGIC) SV03 :=
SV TIMER PICKUP (0.00–3000.00 s) SV04PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV04DO :=
SV INPUT (SELOGIC) SV04 :=
SV TIMER PICKUP (0.00–3000.00 s) SV05PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV05DO :=
SV INPUT (SELOGIC) SV05 :=
SV TIMER PICKUP (0.00–3000.00 s) SV06PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV06DO :=
SV INPUT (SELOGIC) SV06 :=
SV TIMER PICKUP (0.00–3000.00 s) SV07PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV07DO :=
SV INPUT (SELOGIC) SV07 :=
SV TIMER PICKUP (0.00–3000.00 s) SV08PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV08DO :=
SV INPUT (SELOGIC) SV08 :=
SV TIMER PICKUP (0.00–3000.00 s) SV09PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV09DO :=
SV INPUT (SELOGIC) SV09 :=
SV TIMER PICKUP (0.00–3000.00 s) SV10PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV10DO :=
SV INPUT (SELOGIC) SV10 :=
