Schweitzer Engineering Laboratories SEL-751 - Page 394

SET.22
of 78
SEL-751 Settings Sheets Date________________
Logic Settings (SET L Command) SV/Timers
SEL-751 Relay Instruction Manual Date Code 20170927
SV TIMER PICKUP (0.00–3000.00 s) SV11PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV11DO :=
SV INPUT (SELOGIC) SV11 :=
SV TIMER PICKUP (0.00–3000.00 s) SV12PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV12DO :=
SV INPUT (SELOGIC) SV12 :=
SV TIMER PICKUP (0.00–3000.00 s) SV13PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV13DO :=
SV INPUT (SELOGIC) SV13 :=
SV TIMER PICKUP (0.00–3000.00 s) SV14PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV14DO :=
SV INPUT (SELOGIC) SV14 :=
SV TIMER PICKUP (0.00–3000.00 s) SV15PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV15DO :=
SV INPUT (SELOGIC) SV15 :=
SV TIMER PICKUP (0.00–3000.00 s) SV16PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV16DO :=
SV INPUT (SELOGIC) SV16 :=
SV TIMER PICKUP (0.00–3000.00 s) SV17PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV17DO :=
SV INPUT (SELOGIC) SV17 :=
SV TIMER PICKUP (0.00–3000.00 s) SV18PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV18DO :=
SV INPUT (SELOGIC) SV18 :=
SV TIMER PICKUP (0.00–3000.00 s) SV19PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV19DO :=
SV INPUT (SELOGIC) SV19 :=
SV TIMER PICKUP (0.00–3000.00 s) SV20PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV20DO :=
SV INPUT (SELOGIC) SV20 :=
SV TIMER PICKUP (0.00–3000.00 s) SV21PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV21DO :=
SV INPUT (SELOGIC) SV21 :=
SV TIMER PICKUP (0.00–3000.00 s) SV22PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV22DO :=
SV INPUT (SELOGIC) SV22 :=
