Date Code 20170927 Instruction Manual SEL-751 Relay
SET.23
of 78
Date _______________ SEL-751 Settings Sheets
Counters Equations Logic Settings (SET L Command)
Counters Equations
SV TIMER PICKUP (0.00–3000.00 s) SV23PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV23DO :=
SV INPUT (SELOGIC) SV23 :=
SV TIMER PICKUP (0.00–3000.00 s) SV24PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV24DO :=
SV INPUT (SELOGIC) SV24 :=
SV TIMER PICKUP (0.00–3000.00 s) SV25PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV25DO :=
SV INPUT (SELOGIC) SV25 :=
SV TIMER PICKUP (0.00–3000.00 s) SV26PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV26DO :=
SV INPUT (SELOGIC) SV26 :=
SV TIMER PICKUP (0.00–3000.00 s) SV27PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV27DO :=
SV INPUT (SELOGIC) SV27 :=
SV TIMER PICKUP (0.00–3000.00 s) SV28PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV28DO :=
SV INPUT (SELOGIC) SV28 :=
SV TIMER PICKUP (0.00–3000.00 s) SV29PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV29DO :=
SV INPUT (SELOGIC) SV29 :=
SV TIMER PICKUP (0.00–3000.00 s) SV30PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV30DO :=
SV INPUT (SELOGIC) SV30 :=
SV TIMER PICKUP (0.00–3000.00 s) SV31PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV31DO :=
SV INPUT (SELOGIC) SV31 :=
SV TIMER PICKUP (0.00–3000.00 s) SV32PU :=
SV TIMER DROPOUT (0.00–3000.00 s) SV32DO :=
SV INPUT (SELOGIC) SV32 :=
SC PRESET VALUE (1–65000) SC01PV :=
SC RESET INPUT (SELOGIC) SC01R :=
SC LOAD PV INPUT (SELOGIC) SC01LD :=
SC CNT UP INPUT (SELOGIC) SC01CU :=
SC CNT DN INPUT (SELOGIC) SC01CD :=
