Date Code 20170927 Instruction Manual SEL-751 Relay
SET.35
of 78
Date _______________ SEL-751 Settings Sheets
LEA Vsync Voltage Global Settings (SET G Command)
LEA Vsync Voltage
(The following LEA Vsync voltage settings are shown if Slot E := L0)
Phasor Measurement (PMU)
Time and Date Management
VS RATIO CORRECT (0.500–1.500) VSRCF :=
VS ANGLE CORRECT (-10.0 to 10.0 deg) VSPAC :=
EN SYNCHRO PHASOR (Y, N) EPMU :=
(All subsequent PMU settings are hidden if EPMU := N)
MESSAGES PER SEC (1, 2, 5, 10, 12, 15, 20, 30, 60 for FNOM := 60 Hz;
1, 2, 5, 10, 25, 50 for FNOM := 50 Hz) MRATE :=
PMU APPLICATION (FAST, NARROW) PMAPP :=
FREQ BASED COMP (Y, N) PHCOMP :=
STATION NAME (16 characters) PMSTN :=
PMU HARDWARE ID (1–65534) PMID :=
VOLTAGE DATA SET (V1, ALL, NA) (Hidden if Slot Z := Ax) PHDATAV :=
VOLT COMP ANGLE (–179.99 to 180.00 deg) (Hidden if PHDATAV := NA) VCOMP :=
VS COMP ANGLE (–179.99 to 180.00 deg)
(Hidden if Slot E
70 or L0 or PHDATAV = NA) VSCOMP :=
CURRENT DATA SET (I1, ALL, NA) PHDATAI :=
CURRENT COMP ANGLE (–179.99 to 180.00 deg) (Hidden if PHDATAI := NA) ICOMP :=
NUM ANALOG (0–4) NUMANA :=
NUM 16-BIT DIGTAL (0, 1) NUMDSW :=
TRIG REASON BIT 1 (SELOGIC) TREA1 :=
TRIG REASON BIT 2 (SELOGIC) TREA2 :=
TRIG REASON BIT 3 (SELOGIC) TREA3 :=
TRIG REASON BIT 4 (SELOGIC) TREA4 :=
TRIGGER (SELOGIC) PMTRIG :=
CTRL BITS DEFN (NONE, C37.118) IRIGC :=
OFFSET FROM UTC (–24.00 to 24.00 hours; rounded up to quarter) UTC_OFF :=
MONTH TO BEGIN DST (OFF, 1–12) DST_BEGM :=
(The following time and date management settings are hidden if DST_BEGM := OFF)
WEEK OF THE MONTH TO BEGIN DST ((1–3, L) L = Last week of the month) DST_BEGW :=
DAY OF THE WEEK TO BEGIN DST (SUN, MON, TUE, WED, THU, FRI, SAT) DST_BEGD :=
LOCAL HOUR TO BEGIN DST (0–23) DST_BEGH :=
MONTH TO END DST (1–12) DST_ENDM :=
WEEK OF THE MONTH TO END DST (1–3, L) L = Last week of the month DST_ENDW :=
DAY OF THE WEEK TO END DST (SUN, MON, TUE, WED, THU, FRI, SAT) DST_ENDD :=
LOCAL HOUR TO END DST (0–23) DST_ENDH :=
