Schweitzer Engineering Laboratories SEL-751 - Page 413

Date Code 20170927 Instruction Manual SEL-751 Relay
SET.41
of 78
Date _______________ SEL-751 Settings Sheets
Analog Inputs/Outputs Global Settings (SET G Command)
AOx01
AOx02
AOx03
AOx01 ANALOG QTY (Off, 1 analog quantity) AOx01AQ :=
AOx01 TYPE (I, V) AOx01TYP :=
AOx01 AQTY LOW (–2147483647 to +2147483647) AOx01AQL :=
AOx01 AQTY HI (–2147483647 to +2147483647) AOx01AQH :=
If AOx01TYP := I
AOx01 LO OUT VAL (–20.480 to +20.480 mA)
AO
x01L :=
AOx01 HI OUT VAL (–20.480 to +20.480 mA)
AO
x01H :=
If AOx01TYP := V
AOx01 LO OUT VAL (–10.240 to +10.240 V)
AO
x01L :=
AOx01 HI OUT VAL (–10.240 to +10.240 V)
AO
x01H :=
AOx02 ANALOG QTY (Off, 1 analog quantity) AOx02AQ :=
AOx02 TYPE (I, V) AOx02TYP :=
AOx02 AQTY LOW (–2147483647 to +2147483647) AOx02AQL :=
AOx02 AQTY HI (–2147483647 to +2147483647) AOx02AQH :=
If AOx02TYP := I
AOx02 LO OUT VAL (–20.480 to +20.480 mA)
AO
x02L :=
AOx02 HI OUT VAL (–20.480 to +20.480 mA)
AO
x02H :=
If AOx02TYP := V
AOx02 LO OUT VAL (–10.240 to +10.240 V)
AO
x02L :=
AOx02 HI OUT VAL (–10.240 to +10.240 V)
AO
x02H :=
AOx03 ANALOG QTY (Off, 1 analog quantity) AOx03AQ :=
AOx03 TYPE (I, V) AOx03TYP :=
AOx03 AQTY LOW (–2147483647 to +2147483647) AOx03AQL :=
AOx03 AQTY HI (–2147483647 to +2147483647) AOx03AQH :=
If AOx03TYP := I
AOx03 LO OUT VAL (–20.480 to +20.480 mA)
AO
x03L :=
AOx03 HI OUT VAL (–20.480 to +20.480 mA)
AO
x03H :=
If AOx03TYP := V
AOx03 LO OUT VAL (–10.240 to +10.240 V)
AO
x03L :=
AOx03 HI OUT VAL (–10.240 to +10.240 V)
AO
x03H :=
