Schweitzer Engineering Laboratories SEL-751 - Page 414

SET.42
of 78
SEL-751 Settings Sheets Date________________
Global Settings (SET G Command) Station DC Battery Monitor
SEL-751 Relay Instruction Manual Date Code 20170927
AOx04
Station DC Battery Monitor
(The following station DC battery monitor settings are hidden if Slot E  70 or L0)
Input Debounce (Base Unit)
Input Debounce (Slot C)
(Hidden if an input option is not included)
(AC, 0–65000 ms)
Input Debounce (Slot D)
(Hidden if an input option is not included)
(AC, 0–65000 ms)
AOx04 ANALOG QTY (Off, 1 analog quantity) AOx04AQ :=
AOx04 TYPE (I, V) AOx04TYP :=
AOx04 AQTY LOW (–2147483647 to +2147483647) AOx04AQL :=
AOx04 AQTY HI (–2147483647 to +2147483647) AOx04AQH :=
If AOx04TYP := I
AOx04 LO OUT VAL (–20.480 to +20.480 mA)
AO
x04L :=
AOx04 HI OUT VAL (–20.480 to +20.480 mA)
AO
x04H :=
If AOx04TYP := V
AOx04 LO OUT VAL (–10.240 to +10.240 V)
AO
x04L :=
AOx04 HI OUT VAL (–10.240 to +10.240 V)
AO
x04H :=
DC UNDER VOLT PU (OFF, 20.00–300.00 Vdc) DCLOP :=
DC OVER VOLT PU (OFF, 20.00–300.00 Vdc) DCHIP :=
IN101 Debounce (AC, 0–65000 ms) IN101D :=
IN102 Debounce (AC, 0–65000 ms) IN102D :=
IN301 Debounce IN301D :=
IN302 Debounce IN302D :=
IN303 Debounce IN303D :=
IN304 Debounce IN304D :=
IN305 Debounce IN305D :=
IN306 Debounce IN306D :=
IN307 Debounce IN307D :=
IN308 Debounce IN308D :=
IN309 Debounce IN309D :=
IN310 Debounce IN310D :=
IN311 Debounce IN311D :=
IN312 Debounce IN312D :=
IN313 Debounce IN313D :=
IN314 Debounce IN314D :=
IN401 Debounce IN401D :=
IN402 Debounce IN402D :=
IN403 Debounce IN403D :=
IN404 Debounce IN404D :=
IN405 Debounce IN405D :=
IN406 Debounce IN406D :=
IN407 Debounce IN407D :=
IN408 Debounce IN408D :=
IN409 Debounce IN409D :=
IN410 Debounce IN410D :=
IN411 Debounce IN411D :=
IN412 Debounce IN412D :=
IN413 Debounce IN413D :=
IN414 Debounce IN414D :=
