Date Code 20170927 Instruction Manual SEL-751 Relay
SET.43
of 78
Date _______________ SEL-751 Settings Sheets
Input Debounce (Slot E) Global Settings (SET G Command)
Input Debounce (Slot E)
(Hidden if an input option is not included)
(AC, 0–65000 ms)
Breaker Monitor
Data Reset
Access Control
Time Synchronization Source
(Hidden if fiber port is NONE)
Two-Position Disconnect
IN501 Debounce IN501D :=
IN502 Debounce IN502D :=
IN503 Debounce IN503D :=
IN504 Debounce IN504D :=
IN505 Debounce IN505D :=
IN506 Debounce IN506D :=
IN507 Debounce IN507D :=
IN508 Debounce IN508D :=
IN509 Debounce IN509D :=
IN510 Debounce IN510D :=
IN511 Debounce IN511D :=
IN512 Debounce IN512D :=
IN513 Debounce IN513D :=
IN514 Debounce IN514D :=
BREAKER MONITOR (Y, N) EBMON :=
(Hidden if EBMON := N)
CL/OPN OPS SETPT 1 (0–65000) COSP1 :=
CL/OPN OPS SETPT 2 (0–65000) COSP2 :=
CL/OPN OPS SETPT 3 (0–65000) COSP3 :=
kA PRI INTERRPTD 1 (0.00–999.00) KASP1 :=
kA PRI INTERRPTD 2 (0.00–999.00) KASP2 :=
kA PRI INTERRPTD 3 (0.00–999.00) KASP3 :=
BRKR MON CONTROL (SELOGIC) BKMON :=
RESET TARGETS (SELOGIC) RSTTRGT :=
RESET ENERGY (SELOGIC) RSTENRGY :=
RESET MAX/MIN (SELOGIC) RSTMXMN :=
RESET DEMAND (SELOGIC) RSTDEM :=
RESET PK DEMAND (SELOGIC) RSTPKDEM :=
DISABLE SETTINGS (SELOGIC) DSABLSET :=
IRIG TIME SOURCE (IRIG1, IRIG2) TIME_SRC :=
DISC 1 N/O CONT (SELOGIC) 89A2P1 :=
DISC 1 N/C CONT (SELOGIC) 89B2P1 :=
DISC 1 ALM PU (0.00–300.00 sec) 89A2P1D :=
DISC 2 N/O CONT (SELOGIC) 89A2P2 :=
