SEL-751 Settings Sheets Date________________
SET PORT p (p = F, 1, 2, 3, or 4) Command PORT 1
SEL-751 Relay Instruction Manual Date Code 20170927
SEL Synchrophasor Protocol Settings
DNP3 Protocol
(The following DNP3 settings are hidden if DNP3 is not an option)
Session 1
(The DNP IP address of each session (DNPIP1, DNPIP2, etc.) must be unique)
MODBUS TCP PORT 1 (1–65534) (Hidden if EMOD := 0)
See Table SET.1 and the note at the end of Port 1 settings. MODNUM1 :=
MODBUS TCP PORT 2 (1–65534) (Hidden if EMOD := 0 or 1)
Note: See Ta ble SET.1 and the note at the end of Port 1 settings. MODNUM2 :=
MODBUS TIMEOUT 1 (15–900 s) (Hidden if EMOD := 0) MTIMEO1 :=
MODBUS TIMEOUT 2 (15–900 s) (Hidden if EMOD := 0 or 1) MTIMEO2 :=
ENABLE PMU PROCESSING (0–2) EPMIP :=
ENABLE DNP SESSIONS (0–5) EDNP :=
ENABLE SNTP CLIENT (OFF, UNICAST, MANYCAST, BROADCAST) ESNTP :=
ENABLE PMU PROCESSING (0–2) EPMIP :=
PMU OUTPUT 1 TRANSPORT SCHEME (OFF, TCP, UDP_S, UDP_T, UDP_U)
(Hidden if EPMIP := 0) PMOTS1 :=
PMU OUTPUT 1 CLIENT IP ADDRESS [zzz.yyy.xxx.www] (15 characters)
(Hidden if PMOTS1 := OFF) (PMOIPA1 cannot be set to the same address as
IPADDR. IP addresses from 224.0.0.1 through 239.255.255.255 are also valid
when PMOTS1 := UDP_S. IP address 255.255.255.255 is also valid when
PMOTS1 = UDP_S or TCP.) PMOIPA1 :=
PMU OUTPUT 1 TCP/IP PORT NUMBER (1–65534) (Shown only when EPMIP is
not equal to 0 and PMOTS1 is not equal to UDP_S; PMOTCP1 cannot be set to
the same number as PMOTCP2)
Note: See Table SET.1 and the note at the end of Port 1 settings. PMOTCP1 :=
PMU OUTPUT 1 UDP/IP DATA PORT NUMBER (1–65534)
(Shown only when EPMIP is not equal to 0 and PMOTS1 is not equal to TCP) PMOUDP1 :=
PMU OUTPUT 2 TRANSPORT SCHEME (OFF, TCP, UDP_S, UDP_T, UDP_U)
(Hidden if EPMIP := 0 or 1) PMOTS2 :=
PMU OUTPUT 2 CLIENT IP ADDRESS [zzz.yyy.xxx.www] (15 characters)
(Hidden if PMOTS2 := OFF) (PMOIPA2 cannot be set to the same address as
IPADDR. IP addresses from 224.0.0.1 through 239.255.255.255 are also valid
when PMOTS2 = UDP_S. IP address 255.255.255.255 is also valid when
PMOTS2 = UDP_S or TCP.) PMOIPA2 :=
PMU OUTPUT 2 TCP/IP PORT NUMBER (1–65534)
(Shown only when EPMIP := 2 and PMOTS2 is not equal to UDP_S; PMOTCP2
cannot be set to the same number as PMOTCP1)
Note: See Table SET.1 and the note at the end of Port 1 settings. PMOTCP2 :=
PMU OUTPUT 2 UDP/IP DATA PORT NUMBER (1–65534)
(Shown only when EPMIP := 2 and PMOTS2 is not equal to TCP) PMOUDP2 :=
ENABLE DNP SESSIONS (0–5) EDNP :=
(The following DNP3 settings are hidden if EDNP := 0)
DNP TCP and UDP Port (1–65534)
Note: See Table SET.1 and the note at the end of Port 1 settings. DNPNUM :=
DNP Address (0–65519) DNPADR :=
DNP Master IP Address {zzz.yyy.xxx.www} (15 characters) DNPIP1 :=
Transport Protocol (UDP, TCP) DNPTR1 :=
