Date Code 20170927 Instruction Manual SEL-751 Relay
SET.47
of 78
Date _______________ SEL-751 Settings Sheets
PORT 1 SET PORT p (p = F, 1, 2, 3, or 4) Command
Session 2
(All Session 2 settings are hidden if EDNP < 2)
UDP Response Port (REQ, 1–65534) DNPUDP1 :=
DNP Address to Report to (0–65519) REPADR1 :=
DNP Map (1–3) DNPMAP1 :=
Analog Input Default Variation (1–6) DVARAI1 :=
Class for Binary Event Data (0–3) ECLASSB1 :=
Class for Counter Event Data (0–3) ECLASSC1 :=
Class for Analog Event Data (0–3) ECLASSA1 :=
Currents Scaling Decimal Places (0–3) DECPLA1 :=
Voltages Scaling Decimal Places (0–3) DECPLV1 :=
Misc Data Scaling Decimal Places (0–3) DECPLM1 :=
Amps Reporting Dead-band Counts (0–32767) Hidden if ECLASSA1 := 0) ANADBA1 :=
Volts Reporting Dead-band Counts (0–32767) (HiddenifECLASSA1:=0) ANADBV1 :=
Misc Data Reporting Dead-band Counts (0–32767)
(Hidden if ECLASSA1 := 0 and ECLASSC1 := 0) ANADBM1 :=
Minutes for Request Interval (I, M, 1–32767) TIMERQ1 :=
Seconds to Select/Operate Time-Out (0.0–30.0) STIMEO1 :=
Seconds to send Data Link Heartbeat (0–7200) (HiddenifDNPTR1:=UDP) DNPINA1 :=
Event Message Confirm Time-Out (1–50 s) ETIMEO1 :=
Enable Unsolicited Reporting (Y, N) (Hidden if ECLASSA1 := 0, ECLASSB1 := 0,
ECLASSC1 := 0, and ECLASSV1 := 0) UNSOL1 :=
Enable Unsolicited Reporting at Power-Up (Y, N) (HiddenifUNSOL1:=N) PUNSOL1 :=
Number of Events to Transmit On (1–200) (Hidden if UNSOL1 := N) NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 s) (HiddenifUNSOL1:=N) AGEEVE1 :=
Unsolicited Message Max Retry Attempts (2–10) (HiddenifUNSOL1:=N) URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 s) Hidden if UNSOL1 := N) UTIMEO1 :=
DNP Master IP Address {zzz.yyy.xxx.www} (15 characters) DNPIP2 :=
Transport Protocol (UDP, TCP) DNPTR2 :=
UDP Response Port (REQ, 1–65534) DNPUDP2 :=
DNP Address to Report to (0–65519) REPADR2 :=
DNP Map (1–3) DNPMAP2 :=
Analog Input Default Variation (1–6) DVARAI2 :=
Class for Binary Event Data (0–3) ECLASSB2 :=
Class for Counter Event Data (0–3) ECLASSC2 :=
Class for Analog Event Data (0–3) ECLASSA2 :=
Currents Scaling Decimal Places (0–3) DECPLA2 :=
Voltages Scaling Decimal Places (0–3) DECPLV2 :=
Misc Data Scaling Decimal Places (0–3) DECPLM2 :=
Amps Reporting Dead-band Counts (0–32767) (Hidden if ECLASSA2 := 0) ANADBA2 :=
Volts Reporting Dead-band Counts (0–32767) (HiddenifECLASSA2:=0) ANADBV2 :=
