Schweitzer Engineering Laboratories SEL-751 - Page 421

Date Code 20170927 Instruction Manual SEL-751 Relay
SET.49
of 78
Date _______________ SEL-751 Settings Sheets
PORT 1 SET PORT p (p = F, 1, 2, 3, or 4) Command
Session 4
(All Session 4 settings are hidden if EDNP < 4)
Session 5
(All Session 5 settings are hidden if EDNP < 5)
DNP Master IP Address {zzz.yyy.xxx.www} (15 characters) DNPIP4 :=
Transport Protocol (UDP, TCP) DNPTR4 :=
UDP Response Port (REQ, 1–65534) DNPUDP4 :=
DNP Address to Report to (0–65519) REPADR4 :=
DNP Map (1–3) DNPMAP4 :=
Analog Input Default Variation (1–6) DVARAI4 :=
Class for Binary Event Data (0–3) ECLASSB4 :=
Class for Counter Event Data (0–3) ECLASSC4 :=
Class for Analog Event Data (0–3) ECLASSA4 :=
Currents Scaling Decimal Places (0–3) DECPLA4 :=
Voltages Scaling Decimal Places (0–3) DECPLV4 :=
Misc Data Scaling Decimal Places (0–3) DECPLM4 :=
Amps Reporting Dead-band Counts (0–32767) (HiddenifECLASSA4:=0) ANADBA4 :=
Volts Reporting Dead-band Counts (0–32767) (HiddenifECLASSA4:=0) ANADBV4 :=
Misc Data Reporting Dead-band Counts (0–32767)
(Hidden if ECLASSA4 := 0 and ECLASSC4 := 0) ANADBM4 :=
Minutes for Request Interval (I, M, 1–32767) TIMERQ4 :=
Seconds to Select/Operate Time-Out (0.0–40.0) STIMEO4 :=
Seconds to send Data Link Heartbeat (0–7200) (HiddenifDNPTR4:=UDP) DNPINA4 :=
Event Message Confirm Time-Out (1–50 s) ETIMEO4 :=
Enable Unsolicited Reporting (Y, N) (Hidden if ECLASSA4 := 0, ECLASSB4 := 0,
ECLASSC4 := 0, and ECLASSV4 := 0) UNSOL4 :=
Enable Unsolicited Reporting at Power-Up (Y, N) (HiddenifUNSOL4:=N) PUNSOL4 :=
Number of Events to Transmit On (1–200) (Hidden if UNSOL4 := N) NUMEVE4 :=
Oldest Event to Tx On (0.0–99999.0 s) (HiddenifUNSOL4:=N) AGEEVE4 :=
Unsolicited Message Max Retry Attempts (2–10) (HiddenifUNSOL4:=N) URETRY4 :=
Unsolicited Message Offline Time-Out (1–5000 s) (HiddenifUNSOL4:=N) UTIMEO4 :=
DNP Master IP Address {zzz.yyy.xxx.www} (15 characters) DNPIP5 :=
Transport Protocol (UDP, TCP) DNPTR5 :=
UDP Response Port (REQ, 1–65534) DNPUDP5 :=
DNP Address to Report to (0–65519) REPADR5 :=
DNP Map (1–3) DNPMAP5 :=
Analog Input Default Variation (1–6) DVARAI5 :=
Class for Binary Event Data (0–3) ECLASSB5 :=
Class for Counter Event Data (0–3) ECLASSC5 :=
Class for Analog Event Data (0–3) ECLASSA5 :=
Currents Scaling Decimal Places (0–3) DECPLA5 :=
Voltages Scaling Decimal Places (0–3) DECPLV5 :=
