SET.52
of 78
SEL-751 Settings Sheets Date________________
SET PORT p (p = F, 1, 2, 3, or 4) Command PORT 2
SEL-751 Relay Instruction Manual Date Code 20170927
MIRRORED BITS Protocol
(Hidden if PROTO := SEL, EVMSG, or MOD)
DNP Map (1–3) DNPMAP1 :=
Analog Input Default Variation (1–6) DVARAI1 :=
Class for Binary Event Data (0–3) ECLASSB1 :=
Class for Counter Event Data (0–3) ECLASSC1 :=
Class for Analog Event Data (0–3) ECLASSA1 :=
Currents Scaling Decimal Places (0–3) DECPLA1 :=
Voltages Scaling Decimal Places (0–3) DECPLV1 :=
Misc Data Scaling Decimal Places (0–3) DECPLM1 :=
Amps Reporting Dead-band Counts (0–32767) (HiddenifECLASSA1:=0) ANADBA1 :=
Volts Reporting Dead-band Counts (0–32767) (HiddenifECLASSA1:=0) ANADBV1 :=
Misc Data Reporting Dead-band Counts (0–32767)
(Hidden if ECLASSA1 := 0 and ECLASSC1 := 0) ANADBM1 :=
Minutes for Request Interval (I, M, 1–32767) TIMERQ1 :=
Seconds to Select/Operate Time-Out (0.0–30.0) STIMEO1 :=
Data Link Retries (0–15) DRETRY1 :=
Seconds to Data Link Time-Out (0–5) (Hidden if DRETRY1 := 0) DTIMEO1 :=
Event Message Confirm Time-Out (1–50 s) ETIMEO1 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA1 := 0, ECLASSB1 := 0 and ECLASSC1 := 0) UNSOL1 :=
Enable Unsolicited Reporting at Power-Up (Y, N) (HiddenifUNSOL1:=N ) PUNSOL1 :=
Number of Events to Transmit On (1–200) (Hidden if UNSOL1 := N) NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 s) (HiddenifUNSOL1:=N) AGEEVE1 :=
Unsolicited Message Max Retry Attempts (2–10) (HiddenifUNSOL1:=N) URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 s) (HiddenifUNSOL1:=N) UTIMEO1 :=
MB Transmit Identifier
(1-4) TXID :=
MB Receive Identifier
(1-4) RXID :=
MB RX Bad Pickup Time
(0–10000 s) RBADPU :=
MB Channel Bad Pickup
(1–10000 ppm) CBADPU :=
MB Receive Default State
(8 characters) RXDFLT :=
RMB1 Pickup Debounce
Messages (1–8) RMB1PU :=
RMB1 Dropout Debounce
Messages (1–8) RMB1DO :=
RMB2 Pickup Debounce
Messages (1–8) RMB2PU :=
RMB2 Dropout Debounce
Messages (1–8) RMB2DO :=
RMB3 Pickup Debounce
Messages (1–8) RMB3PU :=
RMB3 Dropout Debounce
Messages (1–8) RMB3DO :=
RMB4 Pickup Debounce
Messages (1–8) RMB4PU :=
RMB4 Dropout Debounce
Messages (1–8) RMB4DO :=
RMB5 Pickup Debounce
Messages (1–8) RMB5PU :=
RMB5 Dropout Debounce
Messages (1–8) RMB5DO :=
RMB6 Pickup Debounce
Messages (1–8) RMB6PU :=
RMB6 Dropout Debounce
Messages (1–8) RMB6DO :=
RMB7 Pickup Debounce
Messages (1–8) RMB7PU :=
RMB7 Dropout Debounce
Messages (1–8) RMB7DO :=
