Date Code 20170927 Instruction Manual SEL-751 Relay
SET.53
of 78
Date _______________ SEL-751 Settings Sheets
PORT 3 SET PORT p (p = F, 1, 2, 3, or 4) Command
IEC 60870-5-103 Protocol
(Hidden unless serial port with PROTO := 103)
PORT 3
(EIA-232/485 Port in Slot B)
Communications
RMB8 Pickup Debounce
Messages (1–8) RMB8PU :=
RMB8 Dropout Debounce
Messages (1–8) RMB8DO :=
103 DEVICE ADDRESS (0–254) 103ADDR :=
CYCLIC DATA REPORTING PERIOD (1–3600 s) 103CYC :=
ACCUMULATOR REPORTING PERIOD (OFF, 1–3600 s) 103ACYC :=
ACCUMULATOR REPORTING TRIGGER (1 Relay Word Bit) 103ATRI :=
ENABLE TIME SYNCHRONIZATION (Y, N) 103TIME :=
ENABLE PORT (Y, N) EPORT :=
PROTOCOL (SEL, DNP, MOD, EVMSG, PMU, MBA, MBB, MB8A, MB8B,
MBTA, MBTB, 103) PROTO :=
MAXIMUM ACCESS LEVEL (1, 2, C) MAXACC :=
SPEED (300, 1200, 2400, 4800, 9600, 19200, 38400 bps) SPEED :=
DATA BITS (7, 8 bits)
(Hidden if PROTO := DNP, PMU, MOD, EVMSG, 103, or MB_) BITS :=
PARITY (O, E, N) (Hidden if PROTO := EVMSG, PMU, or MB_) PARITY :=
STOP BITS (1, 2 bits)
(Hidden if PROTO := MOD, EVMSG, or MB_) STOP :=
PORT TIME-OUT (0–30 min)
(Hidden if PROTO := MOD, PMU, EVMSG, 103, or MB_) T_OUT :=
HDWR HANDSHAKING (Y, N) (Hidden if COMMINF := 485 or PROTO := MOD,
DNP, EVMSG, or MB_) RTSCTS :=
LANGUAGE (ENGLISH, SPANISH) LANG :=
SEND AUTOMESSAGE (Y, N)
(Hidden if PROTO := MOD, DNP, PMU, EVMSG, 103, or MB_) AUTO :=
FAST OP MESSAGES (Y, N)
(Hidden if PROTO := MOD, DNP, PMU, EVMSG, 103, or MB_) FASTOP :=
MINIMUM SECONDS FROM DCD TO TX (0.00–1.00 s) (Hidden if PROTO is not
equal to DNP) MINDLY :=
MAXIMUM SECONDS FROM DCD TO TX (0.0–1.00 s) (Hidden if PROTO is not
equal to DNP) MAXDLY :=
SETTLE TIME FROM RTS ON TO TX (OFF, 0.00–30.00 s) (Hidden if PROTO is
not equal to DNP or 103) PREDLY :=
SETTLE TIME FROM TX TO RTS OFF (0.00–30.00 s) (Hidden if PROTO is not
equal to DNP or 103) PSTDLY :=
