SEL-751 Settings Sheets Date________________
SET PORT p (p = F, 1, 2, 3, or 4) Command PORT 3
SEL-751 Relay Instruction Manual Date Code 20170927
Modbus
DNP3 Protocol
(Hidden if PROTO := SEL, EVMSG, MB_, PMU, or MOD.)
Modem Protocol
(For DNP3 session and EIA-232 port only)
MODBUS SLAVE ID (1–247) (Hidden if PROTO := SEL, EVMSG, or MB_) SLAVEID :=
DNP Address (0–65519) DNPADR :=
DNP Address to Report to (0–65519) REPADR1 :=
DNP Map (1–3) DNPMAP1 :=
Analog Input Default Variation (1–6) DVARAI1 :=
Class for Binary Event Data (0–3) ECLASSB1 :=
Class for Counter Event Data (0–3) ECLASSC1 :=
Class for Analog Event Data (0–3) ECLASSA1 :=
Currents Scaling Decimal Places (0–3) DECPLA1 :=
Voltages Scaling Decimal Places (0–3) DECPLV1 :=
Misc Data Scaling Decimal Places (0–3) DECPLM1 :=
Amps Reporting Dead-band Counts (0–32767) (HiddenifECLASSA1:=0) ANADBA1 :=
Volts Reporting Dead-band Counts (0–32767) (HiddenifECLASSA1:=0) ANADBV1 :=
Misc Data Reporting Dead-band Counts (0–32767)
(Hidden if ECLASSA1 := 0 and ECLASSC1 := 0) ANADBM1 :=
Minutes for Request Interval (I, M, 1–32767) TIMERQ1 :=
Seconds to Select/Operate Time-Out (0.0–30.0) STIMEO1 :=
Data Link Retries (0–15) DRETRY1 :=
Seconds to Data Link Time-Out (0–5) (Hidden if DRETRY1 := 0) DTIMEO1 :=
Event Message Confirm Time-Out (1–50 s) ETIMEO1 :=
Enable Unsolicited Reporting (Y, N)
(Hidden if ECLASSA1 := 0, ECLASSB1 := 0 and ECLASSC1 := 0) UNSOL1 :=
Enable Unsolicited Reporting at Power-Up (Y, N) (HiddenifUNSOL1:=N) PUNSOL1 :=
Number of Events to Transmit On (1–200) (Hidden if UNSOL1 := N) NUMEVE1 :=
Oldest Event to Tx On (0.0–99999.0 s) (HiddenifUNSOL1:=N) AGEEVE1 :=
Unsolicited Message Max Retry Attempts (2–10) (HiddenifUNSOL1:=N) URETRY1 :=
Unsolicited Message Offline Time-Out (1–5000 s) (HiddenifUNSOL1:=N) UTIMEO1 :=
Modem Connected to Port (Y, N) MODEM :=
Modem Startup String (30 characters) MSTR :=
Phone Number for Dial-Out (30 characters) PH_NUM1 :=
Phone Number for Dial-Out (30 characters) PH_NUM2 :=
Retry Attempts for Phone 1 Dial-Out (1–20) RETRY1 :=
Retry Attempts for Phone 2 Dial-Out (1–20) RETRY2 :=
Time to Attempt Dial (5–300 s) MDTIME :=
Time Between Dial-Out Attempts (5–3600 s) MDRET :=
